F8 Fingerprint Time Attendance

  • Overview

  • Feature

  • Specification

  • Configuration

  • Download

Product Parameter Parameter Description
Casing material Acrylonitrile Butadiene Styrene (ABS)
Dimension 100x196x53.5mm (L x W x D)
Type of scanner Optical
Language English, Simplified Chinese, Traditional Chinese
User capacity 2200
Transaction storage 50000
Verification method Fingerprint (1:1 , 1:N) , password , RFID card, Keypad
Identification time (sec) <=2 seconds
FAR (%) <=0.0001%
FRR( %) < 1%
Communication RS232, RS485,TCP/IP,USB host,Ethernet
Baud rate (bps) 9600, 19200, 38400, 57600, 115200
Wiegand Wiegand OUT, Wiegand IN
EM lock driving output DC12V-3A
Greeting voice Voice Prompt (language can be selected)
Dispaly LCD with 80 character and figure keypad
Music playback N/A
Power input N/A
USB USB host
