F12 Waterproof IP65 Metal Fingerprint Access Control

  • Overview

  • Feature

  • Specification

  • Configuration

  • Download

F12 is a waterproof metal case standalone fingerprint access control with integrated EM reader.
IP66 waterproof makes it very suitable for outdoor use; with the slim design, it is an ideal choice to install on door frame.
Waterproof, up to IP66
Metal Design & Anti-Vandal
Standalone, one relay
1,000 fingerprint, 2,000 card users
Wiegand 26~44 output
Pulse mode, toggle mode
Multi fingerprints/cards access
Interlock, Support Principal User
User Capacity 3000
Fingerprint 1000
Card 2000
Operating Voltage 12V DC
Idle Current  < 45mA
Proximity Card Reader EM
Radio Technology 125KHz Proximity Card
Read Range 2~4 cm
Fingerprint Reader Optical Fingerprint Module
Resolution 500DPI
Identification time <1S
FAR <0.001%
FRR <0.01%
Wiring Connections Relay output, exit button, alarm, door contact, Wiegand output
Relay One (NO, NC, Common)
Adjustable Relay Output Time 0~99 Seconds (5 seconds default)
Lock Output Load 2 Amp Maximum
Wiegand Interface   Wiegand 26~44bits output
Environment Meets IP66
Operating Temperature -30 - 60 Degree Default
Operating Humidity 10%RH ~ 99%RH
Physical Zinc-Alloy
Color Silver
Dimensions L128 * W48 * H26 (mm)
Unit Weight 400g
Shipping Weight 500g
