Single Door Magnetic Lock(EL-350)

single door electric lock is for glass door, wooden door, fireproof door, sliding door and metal door. Inbuilt dry contacts lock status signal output ( NO,NC,COM) and LED indicator to indicate the lock status.

  • Overview

  • Feature

  • Specification

  • Configuration

  • Download

Collinear Load Test 350kg,800pounds.


Dual Voltage 12 or 24 VDC(optional).


The Standard Voltage is 12VDC when Finished.


MOV Provides Reverse Current Protection.


Suitable For Wooden Door,Glass Door,Metal Door,Fireproof Door.


LED Indicates the Door Status.


Lock Status sensor(NO/NC/COM).


Anti-Residual Magnetism Designed.


High Strength Material,Anodized Aluminum Housing.


Design without Mechanical Failure.


Increase the holding Force,Dual Insulative Housing.


CE Certificate by European Union,MA Certificate by China Public Security Office.

N/A
Product Parameter Parameter Description
Lock Size 285Lx55Wx27.5H(mm)
Armature plate 190Lx45Wx11H(mm)
Holding Force 350kg(800Lbs)
Voltage 12 or 24VDC
Current Draw 12V/480mA or 24V/240mA
Signal Output Dry Contact,Max Rating of Contact Current 3A
LED Red indicates the door is unlock,Green indicates the door is lock
Suitable for Wooden door , Glass door ,Metal door , Fireproof door
Surface Temp ≤+20℃
Operating Temp -10～+55℃(14-131F)
Suitable Humidity 0~95%(non-condensing)
Finishes for Shell Anodized aluminum
Finishes for Magnetic Zinc
Finishes for Armature Zinc
Weight 2.7kg
