ZKTeco TF1700 Outdoor Fingerprint and RFID Terminal

  • Overview

  • Feature

  • Specification

  • Configuration

  • Download

TF1700 is one of the world’s smallest Ethernet connection-based fingerprint terminals, used for access control and time attendance features, with IP65 waterproof housing.
With its IP65 rated rugged waterproof and dustproof structure, TF1700 offers extra durability in harsh conditions such as outdoor environments. It is specially designed for standalone applications such as house, office, shop, garage, factory and others.
The 2013 version of TF1700 is equipped with a sensor cover to protect the optical reader and updated with new firmware that supports ZKAccess3.5 management software which has versatile features and powerful functions.
    Full Access Control Features.
    Slim and Elegant Design.
    Fast and Accurate Fingerprint Algorithm.
    Easy Operation and Management.
    Easy Installation and Connectivity.
    Rugged Structure for Outdoor Installation and Extra Durability.
Fingerprint Sensor Infrared detection fingerprint sensor
Algorithm Version ZK Finger VX10.0
Communication TCP/IP, RS485, USB Host
Fingerprint Capacity 3,000 Fingerprints(8,000 Optional)
Card Capacity 10,000 Cards
Log Capacity 50,000 Transactions
RF Card EM(standard)/Mifare(optional)
Authentication Finger/PIN/Card
Wiegand Signal Wiegand input&output
Ingress Protection Rate IP65
Display 128 x 64 OLED
Keypad 3 x 5 keypads & doorbell
Sound and Interface Buzzer and multi-color LED
Operating Voltage 12VDC 3A
Operating Temperature -10 ~50  (14 ~ 122)
Dimension 62.5mm*185mm*41.5mm (W*H*D)

New product
