Fail safe sturdiness electric bolt is for narrow door(EL-500I)

EL-500I (LED) is an all-metal construction electric bolt .suitable for narrow frame doors which is possess with Double protection for loading current. The bolt is made of 304 stainless steel solid bar with 1000kg holding force and anti-burglar design. It contains the design of magnetic valve, particular photoelectric control structure

  • Overview

  • Feature

  • Specification

  • Configuration

  • Download

Low Temperature, safe & Durable.

Low Power, Environmental Protection.

Special photoelectricity control,three steps current application.

Long Life  with 500000 cycles.

MOV Provides Reverse Current Protection.

Superior Strength Aluminium Alloy,Solid Stainless Steel Bolt.

Autolock Time Delay: 0,3,6,9sec.

Door statue signal output contact(NC.COM).

Double protection for loading current.

Auto-relock if no Action within 5 secs.

Certificate:CE&MA.

Photoelectricity Control,Low Temperature,

  A:The  Low Current is Changed immediately;

  B:When door frame doesn`t coincide with door leaf ,door leaf against the bolt,then the electric bolt will start the low-power function to bring low temperature.

  C:The Photoelectricity Control Technology,prevent the machanical defect.
N/A
Product Parameter Parameter Description
Feature Fail Safe
Face Plate 150Lx25Wx37H(mm)
Bolt 16(length)*13(diameter)(mm)
Voltage DC12V(DC24V)
Start Current 960mA
Standby Current 180mA
Solid Bolt polishing housing, 1000Kg Holding Force
Suitable For Electric Bolt  For Narrow Door
Signal Output Door status Output,NO/COM
Surface Temp Low Temperature
Induction Distance 8mm
Special Designed Tested to 500000 operations
Face place material Stainless Steel
Weight 1.06kg

New product
