Single Door Magnetic Lock(EL-750)

which can withstand 1500Lbs holding force.Suitable for glass door, heavy door,wooden door, fireproof door, sliding door and metal door and so on.The Special design to prevent the residual magnetism makes the access control automation safer and electric lock more durable.

  • Overview

  • Feature

  • Specification

  • Configuration

  • Download


Collinear Load Test 750kg,1500pounds.


Dual Voltage 12 or 24 VDC(optional).


The Standard Voltage is 12VDC when Finished.


MOV Provides Reverse Current Protection.


Anti-Residual Magnetism Designed.


High Strength Material,Anodized Aluminum Housing.


Design without Mechanical Failure.


Increase the holding Force,Dual Insulative Housing.


CE Certificate by European Union,MA Certificate by China Public Security Office.


N/A
Product Parameter Parameter Description
Size

280Lx81.6Wx46H(mm)

Armature plate

190Lx70Wx13H(mm)

Holding Force 750kg(1500Lbs)
Voltage 12 or 24VDC
Current Draw 12V/420mA         24V/210mA
Suitable for Wooden door , Glass door ,Metal door , Fireproof door
Surface Temp ≤+20℃
Operating Temp -10～+55℃(14-131F)
Suitable Humidity 0~95%(non-condensing)
Finishes for Shell Anodized aluminum
Finishes for Magnetic Zinc
Finishes for Armature Zinc
Weight 5.9kg
